개당 허용하중 (Load capacity/pce) |
1,500 kg (3,300 lbs) |
|
4개당 추천하중 (Recommended load/4
pcs) |
3,000 kg (6,600
lbs) |
|
자중 (Net weight) |
F-type |
3.5 kg (7.7 lbs) |
|
Temperature range (사용온도) |
-10 ~ +90℃(+14 ~ +194℉) |
|
|
|
|
|
|
① 취부판 (Top plate) |
Forged steel |
|
② 몸체 (Frame) |
Aluminum diecasted |
|
③ 핸들 (Handle) |
Carbon steel |
|
④ 받침대 (Leveling pad) |
Aluminum |
|
⑤ 바퀴 (Wheel) |
MC nylon |
|
⑥ 취부볼트 (Mounting bolt) |
F-type |
4-M12x1.75P |
|
⑦ 표면처리 (Surface treatment) |
Powder coated & Zinc galvanized |
|
|
|
|
|
|
|
