개당 허용하중 (Load capacity/pce) |
1,000 kg (2,200 lbs) |
|
4개당 추천하중 (Recommended load/4
pcs) |
2,000 kg (4,400
lbs) |
|
자중 (Net weight) |
S-type |
1.9 kg (4.3 lbs) |
|
F-type |
2.2 kg (4.9 lbs) |
|
Temperature range (사용온도) |
-10 ~ +90℃(+14 ~ +194℉) |
|
|
|
|
|
|
① 취부판 (Top plate) |
Forged steel |
|
② 몸체 (Frame) |
Aluminum diecasted |
|
③ 핸들 (Handle) |
Carbon steel |
|
④ 받침대 (Leveling pad) |
Nylon-6 (Aluminum by order) |
|
⑤ 바퀴 (Wheel) |
Nylon-6 |
|
⑥ 취부볼트 (Mounting bolt) |
S-type |
M16x2.0P |
|
F-type |
4-M10x1.5P |
|
⑦ 표면처리 (Surface treatment) |
Powder coated & Zinc galvanized |
|
|
|
|
|
|
|
