개당 허용하중 (Load capacity/pce) |
400 kg (880 lbs) |
|
4개당 추천하중 (Recommended load/4
pcs) |
1,200 kg (2,640
lbs) |
|
자중 (Net weight) |
F-type |
4.2 kg (9.2 lbs) |
|
사용온도 (Temperature range) |
-10 ~ +90℃(+14 ~ +194℉) |
|
|
|
|
|
|
① 취부판 (Top plate) |
Forged steel |
|
② 몸체 (Frame) |
Forged steel |
|
③ 다리(Leg) |
Carbon steel |
|
④ 베어링 (Bearing) |
Ball bearing #6202zz |
|
⑤ 바퀴 (Wheel) |
Polyurethane/Anti-static polyurethane with aluminum
core |
|
⑥ 취부볼트 (Mounting bolt) |
F-type |
4-M10x1.5P |
|
⑦ 표면처리 (Surface treatment) |
Zinc galvanized |
|
|
|
|
|
|
|
