개당 허용하중 (Load capacity/pce)
120 kg (260 lbs)
4개당 추천하중 (Recommended load/4 pcs)
360 kg (790 lbs)
자중 (Net weight)
S-type
1.0 kg (2.2 lbs)
F-type
1.2 kg (2.7 lbs)
사용온도 (Temperature range)
-10 ~ +90℃(+14 ~ +194℉)



① 취부판 (Top plate)
Forged steel
② 몸체 (Frame)
Aluminum diecasted
③ 베어링 (Bearing)
Ball bearing #608zz
④ 바퀴 (Wheel)
Polyurethane/Anti-static polyurethane with aluminum core
⑤ 잠금장치 (Stopper)
Nylon-6
⑥ 취부볼트 (Mounting bolt)
S-type
M12x1.75P
F-type
4-M6x1.0P
⑦ 표면처리 (Surface treatment)
Powder coated (Black/Ivory) & Zinc galvanized
